Farmall 806The Farmall 806 is a 2WD row-crop tractor manufactured by International Harvester from 1963 to 1967.

The Farmall 806 row-crop tractor is equipped with one of two engines: a 5.9 L (361.0 cu·in) six-cylinder diesel engine or a 4.9 L (301.0 cu·in) six-cylinder (gasoline or LP-gas version) engine and one of two transmissions: an unsynchronized gear transmission with dry disc clutch and 8 forward and 4 reverse gears or a two-speed power shift transmission with dry disc clutch and 16 forward and 8 reverse gears.

This tractor could be equipped with the following engines:

  • International Harvester D-361. It is a 5.9 L, 5,916 cm2, (361.0 cu·in) six-cylinder natural aspirated diesel engine with 105.0 mm (4.13 in) of the cylinder bore and 114.0 mm (4.49 in) of the piston stroke. The compression ratio rating is 17.0:1.
  • Interntional Harvester C301. It is a 4.9 L, 4,933 cm2, (301.0 cu·in) six-cylinder natural aspirated gasoline / LP-gas engine. The cylinder bore is 97.0 mm (3.82 in) and the piston stroke is 112.0 mm (4.41 in). The gasoline version of this engine produced 111.5 PS (82.0 kW; 110 HP) at 2,400 rpm of output power.

The Farmall 806 is equipped with hydrostatic power steering, hydraulic dry disc brakes, Open operator station and 159.0 liters (42 US gal.; 35 Imp. gal) fuel tank for gasoline and diesel fuel or 177.9 liters (47 US gal, 39.1 Imp. gal) for LP-gas. The Farmall 806 could be equipped with the International Harvester 2000 loader.

Farmall 806 Specifications

General Specifications
Model Farmall 806
Length 4,080 mm (160.6 in)
Width 2,790 mm (109.8 in)
Height 2,050 mm (80.7 in)
Wheel base 2,570 mm (101.2 in)
Weight Gas: 3,500 kg (7,715 lbs)
Diesel: 3,855 kg (8,500 lbs)
Fuel tank capacity Gas/diesel: 159.0 liters (42 US gal.; 35 Imp. gal)
LP-gas: 177.9 liters (47 US gal, 39.1 Imp. gal)
Battery Diesel: Two 6V, 170 Ah,
Gas/LP: 12V, 60Ah
Cabin type Open operator station
Engine
Engine model International Harvester D-361
Engine type Four-stroke, liquid-cooled, inline
Cylinders 6
Fuel type Diesel
Displacement 5.9 L, 5,916 cm2, (361.0 cu·in)
Bore and stroke 105.0 mm X 114.0 mm (4.13 in X 4.49 in)
Compression ratio 17.0:1
Horsepower
Starter Electric
Coolant capacity: 22.7 L (24 US. qt, 20 Imp. qt.)
Engine
Engine model Interntional Harvester C301
Engine type Four-stroke, liquid-cooled, inline
Cylinders 6
Fuel type Gasoline
Displacement 4.9 L, 4,933 cm2, (301.0 cu·in)
Bore and stroke 97.0 mm X 112.0 mm (3.82 in X 4.41 in)
Horsepower 111.5 PS (82.0 kW; 110.0 HP) at 2,400 rpm
Starter Electric
Transmission and chassis
Chassis 4×2 2WD
Steering type Hydrostatic power
Brakes Hydraulic dry disc
Transmission model
Transmission type Unsynchronized gear with dry disc clutch
Gears 8 forward and 4 reverse
Speed Forward: 30.0 kmh (18.6 mph) Reverse: 15.3 (9.5 mph)
Transmission model Torque Amplifier
Transmission type Two-speed power shift with dry disc clutch
Gears 16 forward and 8 reverse
Speed Forward: 30.0 kmh (18.6 mph) Reverse: 15.3 (9.5 mph)
Tires
Front tires Ag: 6.50-16
Rear tires Ag: 15.5-38
Three-Point Hitch
Caterogy II/I
Control type
Lift capacity (at ends)
PTO (Power take-off shaft)
Rear PTO type Independent
Rear PTO speed 1,000, 540/1,000 rpm
Hydraulic system
Hydraulic type Open center
Pump flow 12.0 gpm (45.4 lpm)
Steering flow 9.0 gpm (34.1 lpm)
PTO pump flow 3.0 gpm (11.4 lpm)
Total flow 24.0 gpm (90.8 lpm)
