John Deere 6230

John Deere 6230The John Deere 6230 is a 2WD or 4WD utility tractor manufactured by John Deere in Mannheim, Baden-Württemberg, Germany from 2007 to 2012.

The JD 6230 is equipped with one of two engines: the John Deere 4045HL280 PowerTech E or the John Deere 4045HL287 PowerTech E engine and one of four transmissions: a fully synchronized transmission with 12 forward and 4 reverse gears, a synchronized with power shuttle transmission with 16 forward and 16 reverse gears, a partial power shift transmission with 16 forward and 16 reverse gears or a partial power shift transmission with 24 forward and 24 reverse gears.

The tractor could be equipped with the following engines:

  • John Deere 4045HL280 PowerTech E (2007-2009). It is a 4.5 L, 4,523 cm2, (276.0 cu·in) four-cylinder turbocharged diesel engine with 106.0 mm (4.17 in) of the cylinder bore and 127.0 mm (5 in) of the piston stroke. The compression ratio rating is 19.0:1. This engine produced 95.3 PS (70.1 kW; 94.0 HP) at 2,300 rpm of output power and 382.4 N·m (39 kg·m, 281.8 ft·lb) at 1,500 rpm of torque.
  • John Deere 4045HL287 PowerTech E (2010-2012). It is a 4.5 L, 4,523 cm2, (276.0 cu·in) six-cylinder turbocharged diesel engine. The cylinder bore is 106.0 mm (4.17 in) and the piston stroke is 127.0 mm (5 in). The compression ratio rating is 19.0:1. This engine produced 96.3 PS (70.8 kW; 95.0 HP) at 2,300 rpm of output power and 383.7 N·m (39.1 kg·m, 282.8 ft·lb) at 1,600 rpm of torque.

The JD 6230 is equipped with hydrostatic power steering, hydraulic wet disc brakes, two-post ROPS or cab (optional) and 165.0 liters (43.6 US gal.; 36.3 Imp. gal) fuel tank.

John Deere 6230 Specifications

General Specifications
Model John Deere 6230
Length
Width
Height
Wheel base 2,400 mm (94.5 in)
Ground clearance 460 mm (18.1 in)
Weight (shipping) 2WD ROPS: 3,890 kg (8,575 lbs)
4WD ROPS: 4,075 kg (8,985 lbs)
4WD Cab: 4,390 kg (9,680 lbs)
Fuel tank capacity 165.0 liters (43.6 US gal.; 36.3 Imp. gal)
Optional: 181.7 liters (48 US gal.; 40 Imp. gal)
Battery 12V
Cabin type Two-post ROPS or Cab (optional)
Engine
Engine model John Deere 4045HL280 PowerTech E
Engine type Four-stroke, liquid-cooled, inline
Cylinders 4
Fuel type Diesel
Displacement 4.5 L, 4,523 cm2, (276.0 cu·in)
Bore and stroke 106.0 mm X 127.0 mm (4.17 in X 5 in)
Compression ratio 19.0:1
Horsepower 95.3 PS (70.1 kW; 94.0 HP) at 2,300 rpm
Torque 382.4 N·m (39 kg·m, 281.8 ft·lb) at 1,500 rpm
Starter Electric
Oil capacity: 15.9 L (16.8 US. qt, 14 Imp. qt.)
Coolant capacity: ROPS: 26.5 L (28 US. qt, 23.3 Imp. qt.)
Cab: 29.1 L (30.7 US. qt, 25.6 Imp. qt.)
Engine
Engine model John Deere 4045HL287 PowerTech E
Engine type Four-stroke, liquid-cooled, inline
Cylinders 6
Fuel type Diesel
Displacement 4.5 L, 4,523 cm2, (276.0 cu·in)
Bore and stroke 106.0 mm X 127.0 mm (4.17 in X 5 in)
Compression ratio 19.0:1
Horsepower 96.3 PS (70.8 kW; 95.0 HP) at 2,300 rpm
Torque 383.7 N·m (39.1 kg·m, 282.8 ft·lb) at 1,600 rpm
Starter Electric
Oil capacity: 15.9 L (16.8 US. qt, 14 Imp. qt.)
Coolant capacity: ROPS: 26.5 L (28 US. qt, 23.3 Imp. qt.)
Cab: 29.1 L (30.7 US. qt, 25.6 Imp. qt.)
Transmission and chassis
Chassis 4×2 2WD or 4×4 MFWD 4WD
Steering type Hydrostatic power
Brakes Hydraulic wet disc
Transmission model John Deere SyncroPlus
Transmission type Fully synchronized
Gears 12 forward and 4 reverse
Speed Forward: 30.7 kmh (19.1 mph) Reverse: 21.2 kmh (13.2 mph)
Transmission oil capacity 51.9 L (13.7 US. gal, 11.4 Imp. gal.)
Transmission model John Deere PowrReverser
Transmission type Synchronized with power shuttle
Gears 16 forward and 16 reverse
Speed Forward: 30.7 kmh (19.1 mph) Reverse: 32.0 kmh (19.9 mph)
Transmission oil capacity 51.9 L (13.7 US. gal, 11.4 Imp. gal.)
Transmission model John Deere PowrQuad
Transmission type Partial power shift with wet disc clutch
Gears 16 forward and 16 reverse
Speed Forward: 30.7 kmh (19.1 mph) Reverse: 32.0 kmh (19.9 mph)
Transmission oil capacity 48.8 L (12.9 US. gal, 10.7 Imp. gal.)
PowrQuad Plus: 50.0 L (13.2 US. gal, 11.0 Imp. gal.)
Transmission model John Deere PowrQuad
Transmission type Partial power shift
Gears 24 forward and 24 reverse
Speed Forward: 40.2 kmh (25.0 mph)
Transmission oil capacity 50.0 L (13.2 US. gal, 11.0 Imp. gal.)
Tires
Front tires Ag: 12.4R24
Rear tires Ag: 18.4R30
Three-Point Hitch
Category II/III
Control type
Lift capacity (at 610 mm/ 24 in) 2,020 kg (4,455 lbs)
PTO (Power take-off shaft)
Rear PTO type Independent
Rear PTO speed 540, 540/1000 rpm
Hydraulic system
Hydraulic type Open-center load sensing or closed-center pressure-flow compensated (optional)
Hydraulic capacity 51.9 L (13.7 US. gal, 11.4 Imp. gal.)
Pressure 2900 psi (199.9 bar)
Valves 1 to 3
Pump flow 21.1 gpm (79.9 lpm)
Optional: 29.0 gpm (109.8 lpm)
