International Harvester 1468

International Harvester 1468The International Harvester 1468 is a 2WD row-crop tractor from the 66 series. This tractor was manufactured by International Harvester in Rock Island, Illinois, USA from 1971 to 1974. The International Harvester 1468 is equipped with a 9.0 L (548.7 cu·in) V8 diesel engine and one of two transmissions: a gear type transmission with 8 forward and 4 reverse gears or a two-speed power shift transmission with 16 forward and 8 reverse gears.

The International Harvester 1468 row-crop tractor used the International DV-550 engine. It is a 9.0 L, 8,992 cm2, (548.7 cu·in) V8 turbocharged diesel engine with 114.0 mm (4.49 in) of the cylinder bore and 110.0 mm (4.33 in) of the piston stroke. This engine produced 147 PS (108.1 kW; 145.0 HP) at 2,600 rpm of output power.

International Harvester 1468 Specifications

General Specifications
ModelInternational Harvester 1468
Length
Width
Height
Wheel base
Weight5,375 kg (11,850 lbs)
Fuel tank capacity
Battery
Cabin typeCab (standard)
Engine
Engine modelInternational DV-550
Engine typeFour-stroke, liquid-cooled, V
Cylinders8
Fuel typeDiesel
Displacement9.0 L, 8,992 cm2, (548.7 cu·in)
Bore and stroke114.0 mm X 110.0 mm (4.49 in X 4.33 in)
Horsepower147 PS (108.1 kW; 145 HP) at 2,600 rpm
StarterElectric
Transmission and chassis
Chassis4×2 2WD
Steering type
Brakes
Transmission model
Transmission typeGear type
Gears8 forward and 4 reverse
Transmission modelTorque Amplifier
Transmission typeTwo-speed power shift
Gears16 forward and 8 reverse
Tires
Front tiresAg: 11L-16
Rear tiresAg: 18.4-38
Three-Point Hitch
CaterogyIII/II
Control type
Lift capacity (at ends)
PTO (Power take-off shaft)
Rear PTO typeIndependent
Rear PTO speed1,000 rpm
Hydraulic system
Hydraulic type
Hydraulic capacity45.4 liters (12.0 US gal, 10.0 Imp. gal)
