Kubota BX2360

Kubota BX2360The Kubota BX2360 is a 4WD compact utility tractor from the BX60 series. This tractor was manufactured by the Kubota from 2009 to 2013. The Kubota BX2360 is equipped with a 0.9 L three-cylinder diesel engine and hydrostatic transmission with infinite (2-range) forward and reverse gears.

The Kubota BX2360 compact utility tractor used the Kubota D902 engine. It is a 0.9 L, 898 cm2, (54.8 cu·in) three-cylinder natural aspirated diesel engine with 72.0 mm (2.83 in) of the cylinder bore and 73.6 mm (2.9 in) of the piston stroke. This engine produced 23.3 PS (17.1 kW; 23.0 HP) at 3,200 rpm of gross horsepower and 18.0 PS (13.2 KW; 17.7 HP) of PTO output power.

The Kubota BX2360 is equipped with hydrostatic power steering, wet disc type brakes, two-post fixed ROPS (canopy available as an option) and 25.0 liters (6.6 US gal.; 5.5 Imp. gal) fuel tank.

Following attachments are available for the Kubota BX2360 compact utility tractor:

  • Kubota RCK54: 54 inches (1,370 mm) mower deck with 3-blades
  • Kubota RCK60B23BX: 60 inches (1,520 mm) mower deck with 3-blades
  • Kubota LA243 loader

Kubota BX2360 Specifications

General Specifications
Model Kubota BX2360
Length 2,120 mm (83.5 in)
Width 1,145 mm (45.1 in)
Height 1,785 mm (70.3 in)
Wheel base 1,400 mm (55.1 in)
Weight 585 kg (1,290 lbs)
Fuel tank capacity 25.0 liters (6.6 US gal.; 5.5 Imp. gal)
Recovery tank 0.4 liters (0.4 US gal.; 0.35 Imp. gal)
Battery 12V, CCA: 535A
Cabin type Two-post fixed ROPS, Canopy (optional)
Engine
Engine model Kubota D902
Engine type Four-stroke, liquid-cooled, inline
Cylinders 3
Fuel type Diesel
Displacement 0.9 L, 898 cm2, (54.8 cu·in)
Bore and stroke 72.0 mm X 73.6 mm (2.83 in X 2.9 in)
Horsepower 23.3 PS (17.1 kW; 23.0 HP) at 3,200 rpm
Torque 56.1 N·m (5.7 kg·m, 41.3 ft·lb)
Starter Electric
Oil capacity: 3.1 L (3.3 US. qt, 2.7 Imp. qt.)
Coolant capacity: 2.7 L (2.9 US. qt, 2.4 Imp. qt.)
Transmission and chassis
Chassis 4×4 MFWD 4WD
Steering type Hydrostatic power
Brakes Wet disc type
Differential lock Rear standard
Transmission model
Transmission type Hydrostatic
Gears Infinite (2-range) forward and reverse
Speed Forward: 13.0 kmh (8.1 mph) Reverse: 10.0 (6.2 mph)
Transmission oil capacity 11.7 L (3.1 US. gal, 2.6 Imp. gal.)
Tires
Front tires Lawn/turf: 18×8.5-10
Rear tires Lawn/turf: 26×12-12
Three-Point Hitch
Caterogy I
Control type Directional control, auto-return lever system
Lift capacity (at ends) 450 kg (992 lbs)
PTO (Power take-off shaft)
Middle PTO type Independent
Middle PTO spped 2,500 rpm
Rear PTO type Independent
Rear PTO spped 540 rpm
Hydraulic system
Hydraulic type Open center
Hydraulic capacity 11.7 L (12.36 US. qt, 10.29 Imp. qt.)
Pump flow 6.2 gpm (23.5 lpm)
