Massey-Harris Pony 11

Massey-Harris Pony 11The Massey-Harris Pony 11 is a 2WD utility tractor manufactured by Massey-Harris in Woodstock, Ontario, Canada from 1947 to 1954. The Massey-Harris Pony 11 is equipped with a 1.0 L (61.9 cu·in) four-cylinder gasoline engine and a unsynchronized gear type transmission with 3 forward and 1 reverse gears and mechanical dry disc clutch.

The Massey-Harris Pony 11 utility tractor used the Continental N62 engine. It is a 1.0 L, 1,015 cm2, (61.9 cu·in) four-cylinder natural aspirated gasoline engine with 60.0 mm (2.36 in) of the cylinder bore and 89.0 mm (3.5 in) of the piston stroke. The compression ratio rating is 6.5:1. This engine produced 11.8 PS (8.7 kW; 11.7 HP) at 1,800 rpm of output power.

The Massey-Harris Pony 11 is equipped with manual steering, differential mechanical contracting band brakes, open operator station and 26.5 liters (7 US gal.; 5.8 Imp. gal) fuel tank.

Massey-Harris Pony 11 Specifications

General Specifications
ModelMassey-Harris Pony 11
Length
Width
Height1,520 mm (59.8 in)
Wheel base1,670 mm (65.7 in)
Weight (operating)857 kg (1,889 lbs)
Fuel tank capacity26.5 liters (7 US gal.; 5.8 Imp. gal)
Battery
Cabin typeOpen operator station
Engine
Engine modelContinental N62
Engine typeFour-stroke, liquid-cooled, inline
Cylinders4
Fuel typeGasoline
Displacement1.0 L, 1,015 cm2, (61.9 cu·in)
Bore and stroke60.0 mm X 89.0 mm (2.36 in X 3.5 in)
Compression ratio6.5:1
Horsepower11.8 PS (8.7 kW; 11.7 HP) at 1,800 rpm
StarterElectric
Oil capacity:3.8 L (4 US. qt, 3.3 Imp. qt.)
Coolant capacity:6.6 L (7 US. qt, 5.8 Imp. qt.)
Spark plugChampion 18625A
Transmission and chassis
Chassis4×2 2WD
Steering typeManual
BrakesDifferential mechanical contracting band
Final driveBull gear
Transmission model
Transmission typeUnsynchronized gear with mechanical dry disc clutch
Gears3 forward and 1 reverse
Speed Forward: 11.3 kmh (7 mph) Reverse: 5.2 kmh (3.2 mph)
Transmission oil capacity3.4 L (0.9 US. gal, 0.7 Imp. gal.)
Tires
Front tires Ag: 4.00x-15
Rear tires Ag: 8-24, 9-24
PTO (Power take-off shaft)
Rear PTO typeOptional
Rear PTO speed540 rpm
Hydraulic system
Hydraulic typeOpen center
Hydraulic capacity1.5 L (0.4 US. gal, 0.3 Imp. gal.)
Pump flow2.5 gpm (9.5 lpm)
