Kubota M6060

Kubota M6060The Kubota M6060 is a 2WD or 4WD utility tractor from the M60 series. This tractor has been manufactured by the Kubota since 2013. The Kubota M6060 is equipped with a 3.3 L four-cylinder, turbocharged diesel engine and power shuttle transmission with wet disc clutch and 8 forward and 8 reverse or 12 forward and 12 reverse gears.

The Kubota M6060 utility tractor used the V3307-CR-TE4 engine. It is a 3.3 L, 3,331 cm2, (203.3 cu·in) four-cylinder, turbocharged diesel engine with 94.0 mm (3.7 in) of the cylinder bore and 120.0 mm (4.72 in) of the piston stroke. This engine produced 64.5 PS (47.4 KW; 63.5 HP) of net horsepower and 56.7 PS (41.7 KW; 55.9 HP) of PTO output power.

The Kubota M6060 is equipped with hydrostatic power steering, mechanically operated (F8/R8 model) or hydraulically operated (F12/R12 model) wet disc brakes, two-post foldable ROPS or Ultra Grand Cab with air-conditioning and 70.0 liters (18.5 US gal.; 15.4 Imp. gal) fuel tank for ROPS version and 90.0 liters (23.8 US. gal, 19.8 Imp. gal.) for Cab version. The Kubota M6060 tractor can be equipped with the Kubota LA1154 loader.

Kubota M7060 versions:

  • M6060HF: 2WD ROPS model
  • M6060HFC: 2WD Cab model
  • M6060HD: 4WD ROPS model
  • M6060HDC: 4WD Cab model

Kubota M6060 Specifications

General Specifications
Model Kubota M6060
Length 2WD: 3,625 mm (142.7 in)
4WD: 3,505 mm (138.0 in)
Width 1,860 mm (73.2 in)
Height 2,565 mm (101 in)
Wheel base 2WD: 2,145 mm (84.4 in)
4WD: 2,110 mm (83.1 in)
Weight 2WD Cab: 2,370 kg (5,226 lbs)
4WD Cab: 2,430 kg (5,358 lbs)
4WD ROPS: 2,270 kg (5,005 lbs)
Fuel tank capacity ROPS: 70.0 liters (18.5 US gal.; 15.4 Imp. gal)
Cab: 90.0 liters (23.8 US. gal, 19.8 Imp. gal.)
Battery 12V CCA: 900A
Cabin type Two-post foldable ROPS or Ultra Grand Cab with air-conditioning
Engine
Engine model V3307-CR-TE4
Engine type Four-stroke, liquid-cooled, inline
Cylinders 4
Fuel type Diesel
Displacement 3.3 L, 3,331 cm2, (203.3 cu·in)
Bore and stroke 94.0 mm X 120.0 mm (3.7 in X 4.72 in)
Horsepower 64.5 PS (47.4 KW; 63.6 HP)
Torque 229.0 Nm (23.36 kg·m; 169 ft·lb)
Starter Electric
Oil capacity: 12.0 L (12.68 US. qt, 10.56 Imp. qt.)
Coolant capacity: 8.0 L (8.45 US. qt, 7.04 Imp. qt.)
Transmission and chassis
Chassis 4×4 MFWD 4WD
Steering type Hydrostatic power
Brakes Mechanically operated wet disc (F8/R8 model)
Hydraulically operated wet disc (F12/R12 model)
Differential Bevel gears with differential lock (Rear)
Transmission model
Transmission type Power shuttle with wet disc clutch
Gears 8 forward and 8 reverse
Speed Forward: 29.0 kmh (18.0 mph) Reverse: 28.5 (17.7 mph)
Transmission model
Transmission type Power shuttle with wet disc clutch
Gears 12 forward and 12 reverse
Speed Forward: 38.9 kmh (24.2 mph) Reverse: 38.3 (23.8 mph)
Tires
Front tires Ag: 7.5-16 (2WD), 9.5-16 (4WD)
Rear tires Ag: 16.9-28
Three-Point Hitch
Caterogy II/I
Control type Position control and top-link draft sensing
Lift capacity 1,900 kg (4,190 lbs)
PTO (Power take-off shaft)
Rear PTO type Independent with electro-hydraulic clutch
Rear PTO spped 540/540E rpm
Hydraulic system
Hydraulic type Open center
Pump flow F8/R8 model: 11.0 gpm (41.6 lpm)
F12/R12 model: 16.2 gpm (61.5 lpm)
