Minneapolis-Moline UDLX

Minneapolis-Moline UDLXThe Minneapolis-Moline UDLX Comfortractor
is a 2WD tractor from the Model U series. This tractor was manufactured by Minneapolis-Moline from 1938 to 1941. The Minneapolis-Moline UDLX is equipped with a 4.6 L (283.7 cu·in) four-cylinder gasoline engine and a synchronized transmission with 5 forward and 1 reverse gears.

The MM UDLX tractor used the Minneapolis-Moline engine. It is a 4.6 L, 4,649 cm2, (283.7 cu·in) four-cylinder natural aspirated gasoline engine with 108.0 mm (4.25 in) of the cylinder bore and 127.0 mm (5 in) of the piston stroke. The compression ratio rating is 5.6:1. This engine produced 36.4 PS (26.8 kW; 35.9 HP) at 1,275 rpm of PTO output power.

The Minneapolis-Moline UDLX is equipped with mechanical drum brakes and cab (standard) with heat, radio, and second seat.

Minneapolis-Moline UDLX Specifications

General Specifications
Model Minneapolis-Moline UDLX
Length 3,580 mm (140.9 in)
Width 1,950 mm (76.8 in)
Height 2,380 mm (93.7 in)
Wheel base 2,050 mm (80.7 in)
Weight 2,900 kg (6,393 lbs)
Fuel tank capacity
Battery
Cabin type Cab standard with heat, radio, and second seat
Engine
Engine model Minneapolis-Moline
Engine type Four-stroke, liquid-cooled, inline
Cylinders 4
Fuel type Gasoline
Displacement 4.6 L, 4,649 cm2, (283.7 cu·in)
Bore and stroke 108.0 mm X 127.0 mm (4.25 in X 5 in)
Compression ratio 5.6:1
Horsepower 36.4 PS (26.8 kW; 35.9 HP) at 1,275 rpm
Starter Electric
Transmission and chassis
Chassis 4×2 2WD
Steering type
Brakes Mechanical drum
Transmission model
Transmission type Synchronized
Gears 5 forward and 1 reverse
Speed Forward: 64.4 kmh (40 mph) Reverse: 2.1 kmh (1.3 mph)
Tires
Front tires Ag: 6.00×16
Rear tires Ag:
