Ford 7740

Ford 7740The Ford 7740 is a 2WD or 4WD row-crop tractor from the PowerStar 40 series. This tractor was manufactured by Ford in Basildon, England from 1991 to 1995. The Ford 7740 is equipped with a 5.0 L (304.0 cu·in) four-cylinder diesel engine and one of four transmission variants.

The Ford 7740 row-crop tractor used the Ford Genesis engine. It is a 5.0 L, 4,982 cm2, (304.0 cu·in) four-cylinder turbocharged diesel engine with 112.0 mm (4.41 in) of the cylinder bore and 127.0 mm (5 in) of the piston stroke. The compression ratio rating is 17.5:1. This engine produced 101.7 PS (74.8 kW; 100.3 HP) at 2,100 rpm of output power.

The Ford 7740 is equipped with hydrostatic power steering, mechanical (7740S) or hydraulic wet disc (7740SL/SLE) brakes, and 94.6 liters (25 US gal.; 20.8 Imp. gal) fuel tank.

Ford 7740 Specifications

General Specifications
Model Ford 7740
Length 4,110 mm (161.8 in)
Width 2WD: 1,950 mm (76.8 in)
4WD: 2,030 mm (79.9 in)
Height (cab) 2,710 mm (106.7 in)
Wheel base 2,360 mm (92.9 in)
Ground clearance (front axle) 2WD: 550 mm (21.7 in)
4WD: 500 mm (19.7 in)
Weight (shipping) 2WD ROPS: 3,320 kg (7,320 lbs)
4WD ROPS: 3,695 kg (8,150 lbs)
2WD Cab: 3,710 kg (8,180 lbs)
4WD Cab: 4,170 kg (9,195 lbs)
Fuel tank capacity 94.6 liters (25 US gal.; 20.8 Imp. gal)
ROPS (optional): 199.5 liters (52.7 US gal.; 43.9 Imp. gal)
Cab (optional): 177.5 liters (46.9 US gal.; 39.0 Imp. gal)
Battery One 12V (ROPS), Two 12V (Cab), CCA 800A
Cabin type Two-post foldable ROPS, Straddle-mount (S) or raised deck (SL/SLE), or Comfort Command Cab (SL/SLE).
Engine
Engine model Ford Genesis
Engine type Four-stroke, liquid-cooled, inline
Cylinders 4
Fuel type Diesel
Displacement 5.0 L, 4,982 cm2, (304.0 cu·in)
Bore and stroke 112.0 mm X 127.0 mm (4.41 in X 5 in)
Compression ratio 17.5:1
Horsepower 101.7 PS (74.8 kW; 100.3 HP) at 2,100 rpm
Torque 560.0 N·m (57.1 kg·m, 412.7 ft·lb) at 1,200 rpm
Starter Electric
Oil capacity: 11.5 L (12.2 US. qt, 10.1 Imp. qt.)
Coolant capacity: ROPS: 14.5 L (15.3 US. qt, 12.8 Imp. qt.)
Cab: 16.0 L (16.9 US. qt, 14.1 Imp. qt.)
Transmission and chassis
Chassis 4×2 2WD or 4×4 MFWD 4WD (optional)
Steering type Hydrostatic power
Brakes Mechanical (S) or hydraulic wet disc (SL/SLE)
Final drive Inboard planetary
Differential lock Mechanical (S) or electro-hydraulic (SL/SLE)
Transmission model EconoShift
Transmission type Constant mesh with dry disc clutch
Gears 8 forward and 2 reverse
Speed Forward: 30.3 kmh (18.8 mph) Reverse: 14.6 kmh (9.1 mph)
Transmission oil capacity 65.9 L (17.4 US. gal, 14.5 Imp. gal.)
Transmission model Dual Power
Transmission type Two-speed power shift with dry disc clutch
Gears 16 forward and 4 reverse
Speed Forward: 30.3 kmh (18.8 mph) Reverse: 14.6 kmh (9.1 mph)
Transmission oil capacity 65.9 L (17.4 US. gal, 14.5 Imp. gal.)
Transmission model SynchroShift
Transmission type Synchronized shuttle with dry disc clutch
Gears 12 forward and 12 reverse
Speed Forward: 30.9 kmh (19.2 mph)
Transmission model ElectroShift/Pulse Command
Transmission type Four-speed power shift
Gears 16 forward and 16 reverse
Speed Forward: 30.7 kmh (19.1 mph)
Transmission oil capacity 60.6 L (16 US. gal, 13.3 Imp. gal.)
Tires
Front tires Ag: 7.50-16
Rear tires Ag: 18.4-30
Three-Point Hitch
Category II
Control type Position control and top-link draft sensing.
Electronic lower-link sensing optional on SLE
Lift capacity (at 610 mm/24 in) 2,815 kg (6,210 lbs)
Optional: 3,735 kg (8,240 lbs)
SLE: 2,975 kg (6,565 lbs)
SLE optional: 3,950 kg (8,710 lbs)
PTO (Power take-off shaft)
Rear PTO type Independent
Rear PTO speed 540/1000 rpm
Hydraulic system
Hydraulic type Open center (S/SL) or closed center load sensing (SLE)
Valves 1 to 4
Pump flow 17.4 gpm (65.9 lpm)
SLE: 20.0 gpm (75.7 lpm)
