Kubota L405

Kubota L405The Kubota L405 is a 2WD or 4WD (L405DT) utility tractor from the L series. This tractor was manufactured by Kubota. The Kubota L405 is equipped with a 1.9 L four-cylinder diesel engine and partially synchronized transmission with 16 forward and 4 reverse gears.

The Kubota L405 utility tractor used the Kubota V1902 engine. It is a 1.9 L, 1,861 cm2, (113.6 cu·in) four-cylinder natural aspirated diesel engine with 85.0 mm (3.35 in) of the cylinder bore and 82.0 mm (3.23 in) of the piston stroke. This engine produced 40.5 PS (29.8 kW; 40.0 HP) of gross output power.

The Kubota L405 is equipped with integral type power steering, wet disc type brakes, open operator station with two-post ROPS and 43.0 liters (11.4 US gal.; 9.5 Imp. gal) fuel tank.

Kubota L405 Specifications

General Specifications
ModelKubota L405
Length3,620 mm (142.5 in)
Width1,540 mm (60.6 in)
Height1,960 mm (77.2 in)
Wheel base 2WD: 1,800 mm (70.9 in)
4WD: 1,820 mm (71.7 in)
Weight 2WD: 1,460 kg (3,220 lbs)
4WD: 1,580 kg (3485 lbs)
Fuel tank capacity43.0 liters (11.4 US gal.; 9.5 Imp. gal)
Battery12V, 100Ah
Cabin typeOpen operator station with two-post ROPS
Engine modelKubota V1902
Engine typeFour-stroke, liquid-cooled, inline
Fuel typeDiesel
Displacement1.9 L, 1,861 cm2, (113.6 cu·in)
Bore and stroke85.0 mm X 82.0 mm (3.35 in X 3.23 in)
Horsepower40.5 PS (29.8 kW; 40.0 HP)
Oil capacity:9.0 L (9.5 US. qt, 7.9 Imp. qt.)
Coolant capacity:7.7 L (8.1 US. qt, 6.8 Imp. qt.)
Transmission and chassis
Chassis4×2 2WD or 4×4 MFWD 4WD
Steering typeIntegral type power steering
BrakesWet disc type
DifferentialBevel gear
Power steering tank2.0 L (2.1 US qts, 1.8 Imp. qts)
Front axle diff. case (4WD)4.0 L (4.2 US qts, 3.5 Imp. qts)
Front axle gear case (4WD)0.8 L (0.85 US.qts, 0.7 Imp. qts)
Transmission model
Transmission typePartially synchronized
Gears16 forward and 4 reverse
Transmission oil capacity28.0 L (7.4 US. gal, 6.2 Imp. gal.)
Front tiresAg: 5.50-16 (2WD), 8-16 (4WD)
Rear tiresAg: 12.4-28
Three-Point Hitch
Control type
Lift capacity (at ends)1,200 kg (2,645 lbs)
PTO (Power take-off shaft)
Rear PTO typeLive
Rear PTO spped540 rpm
