Kubota M5700

Kubota M5700The Kubota M5700 is a 2WD or 4WD utility tractor from the M series. This tractor was manufactured by Kubota from 2001 to 2005. The Kubota M5700 is equipped with a 2.7 L diesel engine and synchronized shuttle transmission with 8 forward and 8 reverse gears.

The Kubota M5700 utility tractor used the Kubota F2803 engine. It is a 2.7 L, 2,746 cm2, (167.6 cu·in) natural aspirated diesel engine with 87.0 mm (3.43 in) of the cylinder bore and 92.0 mm (3.62 in) of the piston stroke. This engine produced 62.4 PS (45.9 kW; 61.6 HP) at 2,800 rpm of maximum output power.

The Kubota M5700 is equipped with power steering, wet disc type brakes, open operator station with two-post ROPS or Cab with air-conditioning (option) and 65.0 liters (17.2 US gal.; 14.3 Imp. gal) fuel tank for ROPS version or 95.0 liters (25.1 US gal, 20.9 Imp. gal) for Cab version. The M5700 tractor could be equipped with the Kubota LA1002 loader.

Kubota M5700 Specifications

General Specifications
Model Kubota M5700
Length 2WD with ROPS: 3,490 mm (137.4 in)
4WD with ROPS: 3,400 mm (134.1 in)
2WD with Cab: 3,570 mm (140.6 in)
4WD with Cab: 3,470 mm (137.0 in)
Width 1.840 mm (72.4 in)
Height ROPS: 2,370 mm (93.3 in)
Cab: 2,510 mm (99.0 in)
Wheel base ROPS: 1,990 mm (78.3 in)
Cab: 2,070 mm (81.7 in)
Weight (ballasted) 3,206 kg (7,070 lbs)
Fuel tank capacity ROPS: 65.0 liters (17.2 US gal.; 14.3 Imp. gal)
Cab: 95.0 liters (25.1 US gal, 20.9 Imp. gal)
Battery 12V
Cabin type Open operator station with two-post ROPS. Cab with air-conditioning (option)
Engine model Kubota F2803
Engine type Four-stroke, liquid-cooled, inline
Cylinders 5
Fuel type Diesel
Displacement 2.7 L, 2,746 cm2, (167.6 cu·in)
Bore and stroke 87.0 mm X 92.0 mm (3.43 in X 3.62 in)
Compression ratio 23.0:1
Horsepower 62.4 PS (45.9 kW; 61.6 HP) at 2,800 rpm
Starter Electric
Oil capacity: 8.0 L (8.5 US. qt, 7 Imp. qt.)
Coolant capacity: 8.0 L (8.5 US. qt, 7 Imp. qt.)
Transmission and chassis
Chassis 4×2 2WD or 4×4 MFWD 4WD
Steering type Power
Brakes Wet disc type
Transmission model
Transmission type Synchronized shuttle
Gears 8 forward and 8 reverse
Front tires Ag: 7.50-16 (2WD), 9.5-22 (4WD)
Rear tires Ag: 16.9-28
Three-Point Hitch
Caterogy II/I
Control type Position control and top-link draft sensing
Lift capacity (at ends) 1,290 kg (2,845 lbs)
PTO (Power take-off shaft)
Rear PTO type Independent
Rear PTO speed 540 rpm
Hydraulic system
Hydraulic type Open center
Hydraulic capacity 52.0 L (54.95 US. qt, 45.75 Imp. qt.)
Valves 1 to 3
Pump flow 11.0 gpm (41.6 lpm)
