Kubota M6800

Kubota M6800The Kubota M6800 is a 2WD or 4WD utility tractor from the M series. This tractor was manufactured by the Kubota from 1997 to 2005. The Kubota M6800 is equipped with a 3.3 L four-cylinder diesel engine and one of two transmissions: synchronized shuttle transmission with dry disc clutch and 8 forward and 8 reverse gears or power shuttle transmission with wet disc clutch and 8 forward and 8 reverse gears.

The Kubota M6800 utility tractor used the Kubota V3300 engine. It is a 3.3 L, 3,318 cm2, (202.5 cu·in) four-cylinder natural aspirated diesel engine with 98.0 mm (3.86 in) of the cylinder bore and 110.0 mm (4.33 in) of the piston stroke. This engine produced 69.1 PS (50.8 kW; 68.0 HP) of net output power and 235.0 N·m (24 kg·m, 173.2 ft·lb) at 1,300-1,50 rpm of torque.

The Kubota M6800 is equipped with hydrostatic power steering, multiple wet disc mechanical brakes, two-post folding ROPS or Cab with air-conditioning (optional) and 65.0 liters (17.2 US gal.; 14.3 Imp. gal) fuel tank.

Following attachments are available for the Kubota M6800 utility tractor:

  • Kubota LA1002 loader
  • Kubota LA1162 loader

Kubota M6800 Specifications

General Specifications
ModelKubota M6800
Length 2WD: 3,530 mm (139.0 in)
4WD: 3,420 mm (134.6 in)
Width1,860 mm (73.2 in)
Height2,450 mm (96.5 in)
Wheel base2050 mm (80.7 in)
Weight 2WD: 2,030 kg (4,475 lbs)
4WD: 2,090 kg (4,608 lbs)
Fuel tank capacity65.0 liters (17.2 US gal.; 14.3 Imp. gal)
Battery12V, CCA: 1000A
Cabin typeTwo-post folding ROPS or Cab with air-conditioning (optional)
Engine
Engine modelKubota V3300
Engine typeFour-stroke, liquid-cooled, inline
Cylinders4
Fuel typeDiesel
Displacement3.3 L, 3,318 cm2, (202.5 cu·in)
Bore and stroke98.0 mm X 110.0 mm (3.86 in X 4.33 in)
Horsepower69.0 PS (50.8 kW; 68.0 HP)
Torque235.0 N·m (24 kg·m, 173.2 ft·lb) at 1,300-1,50 rpm
StarterElectric
Oil capacity:10.7 L (11.3 US. qt, 9.4 Imp. qt.)
Coolant capacity:8.5 L (9 US. qt, 7.5 Imp. qt.)
Transmission and chassis
Chassis4×2 2WD or 4×4 MFWD 4WD
Steering typeHydrostatic power
BrakesMultiple wet disc mechanical
DifferentialBevel gears with differential lock (Front, Rear)
Transmission model
Transmission typeSynchronized shuttle transmission with dry disc clutch
Gears8 forward and 8 reverse
Transmission model
Transmission typePower shuttle with wet disc clutch
Gears8 forward and 8 reverse
Tires
Front tiresAg: 9.5L-15, 7.5-16 (2WD), 9.5-24 (4WD)
Rear tiresAg: 16.9-30
Three-Point Hitch
CaterogyII/I
Control typePosition, draft and mix control
Lift capacity (at ends)2,050 kg (4,520 lbs)
PTO (Power take-off shaft)
Rear PTO typeIndependent with hydraulic wet disc clutch
Rear PTO spped540, 540/540E, 540/1,000 rpm
Hydraulic system
Hydraulic typeOpen center
Pressure2,775 psi (191 bar)
Valves1
Pump flow11.0 gpm (41.6 lpm)
