New Holland TT45A

New Holland TT45AThe New Holland TT45A is a 2WD compact utility tractor from the TT-A series. This tractor was manufactured by New Holland in Dublin, Georgia, USA from 2007 to 2008. The New Holland TT45A is equipped with a 2.0 L (121.7 cu·in) four-cylinder diesel engine and a gear type transmission with 8 forward and 2 reverse gears and dry disc clutch.

The New Holland TT45A compact utility tractor used the Shibaura engine. It is a 2.0 L, 1,994 cm2, (121.7 cu·in) four-cylinder natural aspirated diesel engine with 84.0 mm (3.31 in) of the cylinder bore and 90.0 mm (3.54 in) of the piston stroke. This engine produced 40.5 PS (29.8 kW; 40 HP) at 2,600 rpm of output power.

The New Holland TT45A is equipped with power steering, wet disc brakes, a platform with two-post folding ROPS, and 50.7 liters (13.4 US gal.; 11.2 Imp. gal) fuel tank. This tractor could be equipped with New Holland 610TL loader.

New Holland TT45A Specifications

General Specifications
Model New Holland TT45A
Wheel base
Weight 1,630 kg (3,594 lbs)
Fuel tank capacity 50.7 liters (13.4 US gal.; 11.2 Imp. gal)
Battery 12V, CCA 600A
Cabin type Platform with two-post folding ROPS
Engine model Shibaura
Engine type Four-stroke, liquid-cooled, inline
Cylinders 4
Fuel type Diesel
Displacement 2.0 L, 1,994 cm2, (121.7 cu·in)
Bore and stroke 84.0 mm X 90.0 mm (3.31 in X 3.54 in)
Horsepower 40.5 PS (29.8 kW; 40.0 HP) at 2,600 rpm
Starter Electric
Transmission and chassis
Chassis 4×2 2WD
Steering type Power
Brakes Wet disc
Final drive Bull gear
Differential lock Mechanical rear
Transmission model
Transmission type Gear type with dry disc clutch
Gears 8 forward and 2 reverse
Front tires Ag: –
Rear tires Ag: –
Three-Point Hitch
Category II/I
Control type Position control
Lift capacity (at ends) 1,155 kg (2,547 lbs)
PTO (Power take-off shaft)
Rear PTO type Independent with mechanical dry disc clutch
Rear PTO speed 540 rpm
Hydraulic system
Hydraulic type Open center
Pressure 2538 psi (175 bar)
Valves 0 to 2
Pump flow 9.8 gpm (37.1 lpm)
Steering flow 7.4 gpm (28 lpm)
Total flow 17.2 gpm (65.1 lpm)
ATTENTION! Dear visitors, this site is not a trading platform, an official dealer or a spare parts supplier, so we do not have any price lists, spare parts catalogs, service or owner manuals. We are an information portal and provide the technical specifications.

We try to use verified sources and official documentation, however, differences between sources or errors in entering information may occur. In addition, the characteristics may vary depending on the modification and market. We do not provide advice on technical issues related to the any operation or repair. We do not recommend using provided information for repairing or spare parts ordering, use only official service manuals and spare-parts catalogs.
