John Deere 4760

John Deere 4760The John Deere 4760 is a 2WD or 4WD row-crop tractor from the 4060 series. This tractor was manufactured by John Deere in Waterloo, Iowa, USA from 1992 to 1994. The John Deere 4760 is equipped with a 7.6 L (466.0 cu·in) six-cylinder diesel engine and one of two transmissions: a partial power shift transmission with 16 forward and 6 reverse gears and Perma-Clutch hydraulic wet disc clutch or a full power shift transmission with 15 forward and 4 reverse gears.

The JD 4760 row-crop tractor used the John Deere engine. It is a 7.6 L, 7,636 cm2, (466.0 cu·in) six-cylinder turbocharged aftercooled diesel engine with 116.0 mm (4.57 in) of the cylinder bore and 121.0 mm (4.76 in) of the piston stroke. The compression ratio rating is 15.5:1. This engine produced 177.5 PS (130.5 kW; 175 HP) at 2,200 rpm of PTO output power.

The JD 4760 is equipped with power steering, differential hydraulic wet disc brakes, Sound-Gard cab standard, and 386.1 liters (102 US gal.; 84.9 Imp. gal) fuel tank. This tractor could be equipped with the John Deere 840 loader.

John Deere 4760 Specifications

General Specifications
Model John Deere 4760
Length
Width 3,000 mm (118.1 in)
Height 3,010 mm (118.5 in)
Wheel base 2WD: 3,000 mm (118.1 in)
4WD: 2,970 mm (116.9 in)
Weight 8,485 kg (18,700 lbs)
Fuel tank capacity 386.1 liters (102 US gal.; 84.9 Imp. gal)
Battery Three 12V, CCA 925A
Cabin type Sound-Gard cab standard
Engine
Engine model John Deere
Engine type Four-stroke, liquid-cooled, inline
Cylinders 6
Fuel type Diesel
Displacement 7.6 L, 7,636 cm2, (466.0 cu·in)
Bore and stroke 116.0 mm X 121.0 mm (4.57 in X 4.76 in)
Compression ratio 15.5:1
Horsepower 177.5 PS (130.5 kW; 175.0 HP) at 2,200 rpm
Starter Electric
Oil capacity: 20.8 L (22 US. qt, 18.3 Imp. qt.)
Coolant capacity: 30.3 L (32 US. qt, 26.7 Imp. qt.)
Transmission and chassis
Chassis 4×2 2WD or 4×4 MFWD 4WD
Steering type Power
Brakes Differential hydraulic wet disc
Final drive Inboard planetary
Transmission model John Deere Quad Range
Transmission type Partial power shift with Perma-Clutch hydraulic wet disc clutch
Gears 16 forward and 6 reverse
Transmission model John Deere Power Shift
Transmission type Full power shift
Gears 15 forward and 4 reverse
Speed Forward: 31.0 kmh (19.3 mph) Reverse: 10.3 (6.4 mph)
Tires
Front tires Ag: –
Rear tires Ag: –
Three-Point Hitch
Category III/IIIN
Control type Electrohydraulic draft sensing
Lift capacity (at ends) 3,760 kg (8,290 lbs)
4,555 kg (10,040 lbs)
PTO (Power take-off shaft)
Rear PTO type Independent
Rear PTO speed 1000 rpm
Hydraulic system
Hydraulic type Closed center
Hydraulic capacity 74.9 L (19.8 US. gal, 16.5 Imp. gal.)
Pressure 2350 psi (162 bar)
Valves 3 or 4
Pump flow Quad Range: 35.2 gpm (133.2 lpm)
Power Shift: 31.6 gpm (119.6 lpm)
