John Deere 6130M (2020-2022)

John Deere 6130M (2020-2022)The John Deere 6130M is a 2WD or 4WD utility tractor from the 6M series. This tractor was manufactured by John Deere in Mannheim, Baden-Württemberg, Germany from 2015 to 2022. This second generation was manufactured from 2020 to 2022. The John Deere 6130M is equipped with a 4.5 L (276.0 cu·in) four-cylinder diesel engine and one of four transmission variants.

The JD 6130M utility tractor used the John Deere 4045HL555 engine. It is a 4.5 L, 4,523 cm2, (276.0 cu·in) four-cylinder turbocharged diesel engine with 105.0 mm (4.13 in) of the cylinder bore and 127.0 mm (5 in) of the piston stroke. This engine produced 131.8 PS (96.9 kW; 130.0 HP) at 2,100 rpm of output power and 609.1 N·m (62.1 kg·m, 448.9 ft·lb) at 1,600 rpm of torque.

The John Deere 6130M is equipped with power steering, hydraulic wet disc brakes, cab (standard) with air-conditioning and 194.9 liters (51.5 US gal.; 42.9 Imp. gal) fuel tank.

Following attachments are available for the John Deere 6130M utility tractor:

  • John Deere 640R loader
  • John Deere 640R MSL loader

John Deere 6130M Specifications

General Specifications
Model John Deere 6130M
Length 4,480 mm (176.4 in)
Width
Height (cab) 2,890 mm (113.8 in)
Wheel base 2,580 mm (101.6 in)
Ground clearance (front axle) 490 mm (19.3 in)
Weight 10,450 kg (23,038 lbs)
Fuel tank capacity 194.9 liters (51.5 US gal.; 42.9 Imp. gal)
Battery 12V, 154Ah
Cabin type Cab (standard) with air-conditioning
Engine
Engine model John Deere 4045HL555
Engine type Four-stroke, liquid-cooled, inline
Cylinders 4
Fuel type Diesel
Displacement 4.5 L, 4,523 cm2, (276.0 cu·in)
Bore and stroke 105.0 mm X 127.0 mm (4.13 in X 5 in)
Horsepower 131.8 PS (96.9 kW; 130.0 HP) at 2,100 rpm
Torque 609.1 N·m (62.1 kg·m, 448.9 ft·lb) at 1,600 rpm
Starter Electric
Oil capacity: 16.0 L (16.9 US. qt, 14.1 Imp. qt.)
Coolant capacity: 22.1 L (23.4 US. qt, 19.4 Imp. qt.)
Transmission and chassis
Chassis 4×2 2WD or 4×4 MFWD 4WD
Steering type Power
Brakes Hydraulic wet disc
Final drive Planetary
Transmission model PowrQuad
Transmission type Four-speed power shift
Gears 16 forward and 16 reverse
Speed Forward: 29.9 kmh (18.6 mph) Reverse: kmh (0 mph)
Transmission model PowrQuad/AutoQuad
Transmission type Four-speed power shift
Gears 24 forward and 24 reverse
Speed Forward: 39.3 kmh (24.4 mph) Reverse: kmh (0 mph)
Transmission model CommandQuad
Transmission type Four-speed power shift
Gears 24 forward and 24 reverse
Speed Forward: 39.3 kmh (24.4 mph) Reverse: kmh (0 mph)
Transmission model AutoPowr
Transmission type Infinitely variable transmission (IVT)
Gears Infinite forward and reverse
Tires
Front tires Ag: 540/65R24
Rear tires Ag: 600/65R38
Three-Point Hitch
Category II/IIIN
Control type Electronic lower link draft sensing
Lift capacity 5,000 kg (11,025 lbs)
5,695 kg (12,556 lbs)
Front Hitch
Category IIIN
Lift capacity 4,400 kg (9,700 lbs)
PTO (Power take-off shaft)
Front PTO type Independent with electro-hydraulic wet disc clutch
Front PTO speed 1,000 rpm
Rear PTO type Independent with electro-hydraulic wet disc clutch
Rear PTO speed 540/1,000 rpm
Hydraulic system
Hydraulic type Open center or closed center PFC
Valves Rear: 2 to 4
Front: 0 to 3
Pump flow Open: 21.2 gpm (80.3 lpm)
Closed: 30.0 gpm (113.6 lpm)
