Mahindra 2555

Mahindra 2555The Mahindra 2555 is a 2WD compact utility tractor from the 2500 series. This tractor has been manufactured by the TYM for Mahindra since 2016. The Mahindra 2555 is equipped with a 2.6 L four-cylinder diesel engine and one of two transmissions: a hydrostatic transmission with Infinite (3-range) forward and reverse gears or shuttle transmission with 12 forward and 12 reverse gears.

The Mahindra 2555 compact utility tractor used the Mahindra engine. It is a 2.6 L, 2,646 cm2, (161.5 cu·in) four-cylinder turbocharged intercooled diesel engine with 96.0 mm (3.78 in) of the cylinder bore and 122.0 mm (4.8 in) of the piston stroke. The compression ratio rating is 17.2:1. This engine produced 55.8 PS (41.0 kW; 55.0 HP) at 2,300 rpm of maximum output power.

The Mahindra 2555 is equipped with power steering, wet disc brakes, two-post foldable ROPS or Cab with air-conditioning (optional) and 60.0 liters (15.9 US gal.; 13.2 Imp. gal) fuel tank.

Following attachments are available for the Mahindra 2555 compact utility tractor:

  • Mahindra 2555L loader
  • Mahindra 75BL backhoe

Mahindra 2555 Specifications

General Specifications
ModelMahindra 2555
Length3,400 mm (133.9 in)
Width ROPS: 1,800 mm (70.9 in)
Cab: 1,810 mm (71.3 in)
Height2590 mm (102 in)
Wheel base
Weight ROPS: 1,839 kg (4,054 lbs)
Cab: 1,950 kg (4,300 lbs)
Fuel tank capacity60.0 liters (15.9 US gal.; 13.2 Imp. gal)
Battery12V, 96Ah
Cabin typeTwo-post foldable ROPS or Cab with air-conditioning (optional)
Engine modelMahindra
Engine typeFour-stroke, liquid-cooled, inline
Fuel typeDiesel
Displacement2.6 L, 2,646 cm2, (161.5 cu·in)
Bore and stroke96.0 mm X 122.0 mm (3.78 in X 4.8 in)
Compression ratio17.2:1
Horsepower55.8 PS (41.0 kW; 55.0 HP) at 2,300 rpm
Transmission and chassis
Chassis4×4 MFWD 4WD
Steering typePower
BrakesWet disc
Transmission model
Transmission typeHydrostatic with wet disc clutch
GearsInfinite (3-range) forward and reverse
Transmission model
Transmission typeShuttle with dry disc clutch
Gears12 forward and 12 reverse
Front tires Ag: 9.5×16
Lawn/turf: LSW305-521
Industrial: 12×16.5
Rear tires Ag: 14.9×24
Lawn/turf: LSW750-648
Industrial: 16.9×24
Three-Point Hitch
Control typePosition control
Lift capacity (at ends)1,500 kg (3,308 lbs)
PTO (Power take-off shaft)
Rear PTO typeIndependent
Rear PTO spped540 rpm
Hydraulic system
Hydraulic typeOpen center
Valves1 to 2
Pump flow Shuttle: 9.5 gpm (36.0 lpm)
Hydro: 9.7 gpm (36.7 lpm)
Steering flow5.0 gpm (18.9 lpm)
