The Toro SS5000 74630 is a 2WD zero-turn mower from the SS series. This mower was manufactured by Toro from 2011 to 2012. The Toro SS5000 74630 is equipped with a 0.7 L two-cylinder gasoline engine and hydrostatic transmission with infinite (2-range) forward and reverse gears.
The Toro SS5000 74630 zero-turn mower used the Kawasaki FR651V engine. It is a 0.7 L, 726 cm2, (44.3 cu·in) two-cylinder natural aspirated gasoline engine with 78.0 mm (3.07 in) of the cylinder bore and 76.0 mm (2.99 in) of the piston stroke. This engine produced 22.3 PS (16.4 kW; 22.0 HP) of maximum output power.
The Toro SS5000 74630 is equipped with power steering, open operator station and 11.4 liters (3 US gal.; 2.5 Imp. gal) fuel tank and mid-mount Toro 50 in (1,270 mm) mower deck with 3-blades and manual lever lift.
Toro SS5000 74630 Specifications
|Model||Toro SS5000 74630|
|Length||1,850 mm (72.8 in)|
|Height||1,020 mm (40.2 in)|
|Fuel tank capacity||11.4 liters (3 US gal.; 2.5 Imp. gal)|
|Cabin type||Open operator station|
|Engine model||Kawasaki FR651V|
|Engine type||Four-stroke, air-cooled, V|
|Displacement||0.7 L, 726 cm2, (44.3 cu·in)|
|Bore and stroke||78.0 mm X 76.0 mm (3.07 in X 2.99 in)|
|Horsepower||22.3 PS (16.4 kW; 22 HP) at rpm|
|Oil type||API: SJ or higher, SAE 10W-40, 10W-30|
|Spark plug||NGK BPR4ES|
|Transmission and chassis|
|Transmission model||Hydro-Gear ZT-2200|
|Gears||Infinite (2-range) forward and reverse|
|Speed||Forward: 11.3 kmh (7 mph) Reverse: 4.8 (3 mph)|
|Front tires||Lawn/turf: 13×5|
|Rear tires||Lawn/turf: 18×9.5|
|PTO (Power take-off shaft)|
|Middle PTO type||Independent with electric clutch|
|Middle PTO speed||–|
