Wheel Horse 417-8

Wheel Horse 417-8The Wheel Horse 417-8 is a 2WD garden tractor from the 400 series. This tractor was manufactured by Wheel Horse in South Bend, Indiana, USA from 1985 to 1986. The Wheel Horse 417-8 is equipped with a 0.7 L (42.2 cu·in) two-cylinder gasoline engine and a belt-driven gear transmission with 6 forward and 2 reverse gears.

The Wheel Horse 417-8 garden tractor used the Kohler KT17QS engine. It is a 0.7 L, 691 cm2, (42.2 cu·in) two-cylinder natural aspirated gasoline engine with 79.0 mm (3.11 in) of the cylinder bore and 70.0 mm (2.76 in) of the piston stroke. This engine produced 17.3 PS (12.7 kW; 17.0 HP) at 3,600 rpm of output power.

The Wheel Horse 417-8 is equipped with manual steering, an open operator station, and 11.4 liters (3 US gal.; 2.5 Imp. gal) fuel tank.

Following attachments are available for the Wheel Horse 417-8 garden tractor:

  • Mid-mount Wheel Horse 910 mm (36 in) mower deck
  • Mid-mount Wheel Horse 1,060 mm (42 in) mower deck
  • Mid-mount Wheel Horse 1,210 mm (48 in) mower deck

Wheel Horse 417-8 Specifications

General Specifications
Model Wheel Horse 417-8
Length 1,650 mm (65 in)
Width 960 mm (37.8 in)
Height 1,050 mm (41.3 in)
Wheel base 1,150 mm (45.3 in)
Weight 265 kg (584 lbs)
Fuel tank capacity 11.4 liters (3 US gal.; 2.5 Imp. gal)
Battery 12V
Cabin type Open operator station
Engine
Engine model Kohler KT17QS
Engine type Four-stroke, air-cooled
Cylinders 2
Fuel type Gasoline
Displacement 0.7 L, 691 cm2, (42.2 cu·in)
Bore and stroke 79.0 mm X 70.0 mm (3.11 in X 2.76 in)
Horsepower 17.3 PS (12.7 kW; 17.0 HP) at 3,600 rpm
Starter Electric
Transmission and chassis
Chassis 4×2 2WD
Steering type Manual
Brakes –
Transmission model Wheel Horse 110995
Transmission type Belt-driven gear
Gears 6 forward and 2 reverse
Speed Forward: 8.8 kmh (5.5 mph) Reverse: 4.2 kmh (2.6 mph)
Tires
Front tires Lawn/turf: 15×6.00-6
Rear tires Lawn/turf: 22×7.50-12
Three-Point Hitch
Category Sleeve hitch
Control type –
Lift capacity (at ends) –
